Exhausting chemical hood LIGHT 900, using filters of activated carbon for toxic polluting fumes and for bad smelling aerosol. LIGHT 900 is a hood suitable for the handling of organic and inorganic materials which produce toxic or bad smelling fumes. All the molecules harmful to breathing and to the room are retained in its filters. No fixed installation or pipe-fitting is required with it. It can then be installed over any bench
Technical specifications
o Casing realized in powdered painted steel. o Removable working benchtop in stainless steel 304
o Bottom in stainless steel AISI 304
o Working surface: 2 liter
o Filtered air volume: 320 mc/hour. o Avarage air speed: 0.50 m/sec
o Volume 0,34 mc
o Lighting by 18 W fluorescent lamp. o Pre filter in synthetic material (75% efficiency)
o Carbon filters. oPolicarbonate membrane control panel. Microprocessor electronic circuit with flash memory. o Two speed fan switch. o Emergency speed switch. o Micro switch control the air flow speed during the opening of front panel. o Front panel with service outlet switch. o Service outlet digital work counter (max. 9999 h). o Service outlet programmable (max. 96 hours). o Blinking display in case of lack of tension of service outlet. o Filter digital work counter (max. 9999 hours). o Inner dimensions: mm 700x630x770h
o Overall dimensions: mm 750x670x1060h
o Weight Kg 54
o Power supply: 230V-50Hz. o Electrical input: 110 W.
Optional accessories
o Air conveyor connector diam. 150 mm. with anti-wind air grating. Is recommend to install when hood
is equipped with carbon that can retain until 5% as referred to the weight of carbon present into filter. (ex.charcoal filters for special applications)
o Fixed or wheeled support table for hood with rolled anti-scratch top. Dim. 800x800x830h
